Denon AVR-E400 Service Manual

VIDEO
5
VIDEO PCB ASS'Y
NOTE:
X2000E3 : U.S.A. & Canada model X2000E2 : Europe model X2000E1C : China model X2000E1 : Asia model X2000K : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4210-4212 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 3
IC4701 236810090504S ILX3232D 3V3 RS232 INTERFACE TRANSCEIVER SOP16 X2000E3 J046323200020S 1
IC5000 232810005504S BD7628F-E2 2CH VIDEO AMP SOP8P J127762800010S 1
IC5001 963239100770S TC4051BF SINGLE 8CH MUX/DEMUX SOP16 J040405101110S 1
IC5003 963235100630S NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
＊
Q4200,4201 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA X2000E1C,E2,E3,K J522020011210S 2
Q4204 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA X2000E1C,E2,E3,K J520101411210S 1
Q4205 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA X2000E1C,E2,E3,K J522101411210S 1
Q4206 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA X2000E1C,E2,E3,K J520101411210S 1
Q4207 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4208 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4209 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4214 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
ZD4200 963202500290D ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
RESISTOR GROUP
R4200,4201 nsp 220-J,1/16W-1608REEL X2000E1C,E2,E3,K C20002216M160S 2
R4202,4203 nsp 100K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001046M160S 2
R4204 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R4212,4213 nsp 100K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001046M160S 2
R4214,4215 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R4222 nsp 470-J,1/16W-1608REEL X2000E1C,E2,E3,K C20004716M160S 1
R4223,4224 nsp 10K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001036M160S 2
R4225 nsp 470-J,1/16W-1608REEL X2000E1C,E2,E3,K C20004716M160S 1
R4226 nsp 10K-J,1/16W-1608REEL
C20001036M160S 1
R4227,4228 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4237 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4238,4239 nsp 470-J,1/16W-1608REEL X2000E1C,E2,E3,K C20004716M160S 2
R4240 nsp 470K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20004746M160S 1
R4241 nsp 1K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001026M160S 1
R4242,4243 nsp 470K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20004746M160S 2
R4258 nsp 10K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001036M160S 1
R4291 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4295,4296 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R4297 nsp 1K-J,1/5W-52RE-AX C00001026P520S 1
R4302 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4708,4709 nsp 1K-J,1/16W-1608REEL X2000E3 C20001026M160S 2
R4710 nsp 0-J,1/16W-1608REEL X2000E3 C20000006M160S 1
R4711 nsp 1K-J,1/16W-1608REEL X2000E3 C20001026M160S 1
R4714 nsp 1K-J,1/16W-1608REEL X2000E3 C20001026M160S 1
R5000 nsp 820-D,1/16W-1608REEL C20008211M160S 1
R5001 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R5003 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R5005 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5006 nsp 680-D,1/16W-1608REEL C20006811M160S 1
R5007 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5008-5010 nsp 10K-J,1/16W-1608REEL C20001036M160S 3
R5011 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5013,5014 nsp 75-J,1/16W-1608REEL C20007506M160S 2
R5016 nsp 150-J,1/16W-1608REEL
C20001516M160S 1
R5018 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5020 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R5022 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5024 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R5026 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5033-5035 nsp 75-J,1/16W-1608REEL C20007506M160S 3
R5036 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5069-5071 nsp 10K-J,1/16W-1608REEL C20001036M160S 3
CAPACIITORS GROUP
C4200,4201 nsp COG330PF-J/50V-1608REEL X2000E1C,E2,E3,K D010331167160S 2
C4202,4203 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040220087060S 2
C4204 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4205,4206 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C4207,4208 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 2
C4220 00D9630244606 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) X2000E1C,E2,E3,K D040R10087080S 1
C4221,4222 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040220087060S 2
C4247 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4248 00D9630244606 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080S 1
C4706 nsp X7R0.1UF-K/50V-1608REEL X2000E3 D011104577160S 1
C4707 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E3 D040100087070S 1
C4711,4712 nsp X7R0.1UF-K/50V-1608REEL X2000E3 D011104577160S 2
C4716,4717 nsp X7R0.1UF-K/50V-1608REEL X2000E3 D011104577160S 2
C4718,4719 nsp COG33PF-J/50V-1608REEL X2000E3 D010330167160S 2
C5000 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5001 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C5002,5003 00D9630224503
22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C5004 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C5006,5007 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 2
C5011 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5012 nsp COG68PF-J/50V-1608REEL D010680167160S 1
C5013,5014 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C5015,5016 nsp COG68PF-J/50V-1608REEL D010680167160S 2
C5017,5018 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C5019,5020 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C5021 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C5022 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5048 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 1
C5051 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 1
OTHER PARTS GROUP
BKT4702 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT5001,5002 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 2
CLAMP300 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4002 nsp C125Z2-15 15P BtoB SOCKET(FEMALE) P=1.25MM L109012521520S 1
CN4003 nsp C125Z2-19 19P BtoB SOCKET(FEMALE) P=1.25MM L109012521920S 1
The symbols in the column "Remarks" indicate the following destinations.
E400E3 : U.S.A. & Canada model

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
