Denon AVR-E400 Service Manual

7CH_AMP
9
7CH_AMP PCB ASS'Y
NOTE:
X2000E3 : U.S.A. & Canada model X2000E2 : Europe model X2000E1C : China model X2000E1 : Asia model X2000K : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D402 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D403,404 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D405,406 nsp JUMPER (0.6/52MM) L045084006040S 2
D408 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D409,410 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D411,412 nsp JUMPER (0.6/52MM) L045084006040S 2
D414 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D415,416 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D417,418 nsp JUMPER (0.6/52MM) L045084006040S 2
D420 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D421,422 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D423,424 nsp JUMPER (0.6/52MM) L045084006040S 2
D426 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D427,428 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D429,430 nsp JUMPER (0.6/52MM) L045084006040S 2
D432 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D433,434 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D435,436 nsp JUMPER (0.6/52MM) L045084006040S 2
D438 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D439,440 00D2760401905 1SS133-DO34-AXIAL LRC E400E3,X2000E3 K000013300040S 2
D441,442 nsp JUMPER (0.6/52MM) L045084006040S 2
Q401 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q403 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q405 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q406 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q407,408 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q412 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q413 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q415 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q417 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 1
Q418 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q419,420 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q424 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q425 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q427 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q430 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q431,432 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q436 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q437 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q439 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q442 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q443,444 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q448 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q449 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q451 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q454 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q455,456 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q460 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q461 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q463 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q466 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q467,468 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q472
00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q473 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q475 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q478 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q479,480 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q484 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
ZD401 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD402,403 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD404 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD405,406 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD407 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD408,409 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD410 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD411,412 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD413 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD414,415 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD416 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD417,418 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
ZD419 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD420,421 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH E400E3,X2000E3 K06003R344522S 2
RESISTOR GROUP
R401 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R402 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R404 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R406 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R407 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R408 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R409 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R410 nsp JUMPER (0.6/52MM) L045084006040S 1
R411 nsp 150K-J,1/5W-52RE-AX X400E3,E3 C00001546P520S 1
R411 nsp 120K-J,1/5W-52RE-AX X2000E1C,E2,K C00001246P520S 1
R412 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R413,414 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R415 963125012630S 22-J,1W-5REEL C060022065050S 1
R416 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R417 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R419 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R421 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R423 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R424,425 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R426 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R427 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R428 00MGD05152160 1.5K-J,1/5W-52RE-AX C00001526P520S 1
R429 963121006300M 33K-J,1/5W-52RE-AX C00003336P520S 1
R430,431 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R432 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R434 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R435 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R436 963121006310M 470K-J,1/5W-52RE-AX C00004746P520S 1
R437 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R438 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 1
R439 963125012630S 22-J,1W-5REEL C060022065050S 1
R440 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
The symbols in the column "Remarks" indicate the following destinations.
E400E3 : U.S.A. & Canada model

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
