Denon AVR-E400 Service Manual

7CH_AMP
10
REF No. Part No. Part Name Remarks Q'ty New Ver
R441 nsp 1.2K-J,1W-5REEL C060012265050S 1
R442 nsp JUMPER (0.6/52MM) L045084006040S 1
R443 nsp 47-J,1W-R.REEL C060047065060S 1
R444 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R445 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R446 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R450 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R451 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R452 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R453 nsp JUMPER (0.6/52MM) L045084006040S 1
R454 nsp 150K-J,1/5W-52RE-AX X400E3,E3 C00001546P520S 1
R454 nsp 120K-J,1/5W-52RE-AX X2000E1C,E2,K C00001246P520S 1
R455 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R456,457 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R458 963125012630S 22-J,1W-5REEL C060022065050S 1
R459 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R460 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R462 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R466 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R467,468 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R469 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R471 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R472 00MGD05152160 1.5K-J,1/5W-52RE-AX C00001526P520S 1
R473 963121006300M 33K-J,1/5W-52RE-AX C00003336P520S 1
R474,475 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R476 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R478 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R479 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R480 963121006310M 470K-J,1/5W-52RE-AX C00004746P520S 1
R481 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R482 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 1
R483 963125012630S 22-J,1W-5REEL C060022065050S 1
R484 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R485 nsp 1.2K-J,1W-5REEL C060012265050S 1
R486 nsp JUMPER (0.6/52MM) L045084006040S 1
R487 nsp 47-J,1W-R.REEL C060047065060S 1
R488 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R489 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R490 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R493 00D9630337908 33-J,1W-R.REEL C060033065050S 1
R494 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R495 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R496 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R497 nsp JUMPER (0.6/52MM) L045084006040S 1
R498 nsp 150K-J,1/5W-52RE-AX X400E3,E3 C00001546P520S 1
R498 nsp 120K-J,1/5W-52RE-AX X2000E1C,E2,K C00001246P520S 1
R499 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R500,501 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R502 963125012630S 22-J,1W-5REEL C060022065050S 1
R503 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R504 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R506 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R507 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R510 nsp 10K-J,1/16W-1608REEL C20001036M160S
1
R511,512 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R513 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R514 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R515 00MGD05152160 1.5K-J,1/5W-52RE-AX C00001526P520S 1
R516 963121006300M 33K-J,1/5W-52RE-AX C00003336P520S 1
R517,518 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R519 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R520 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R521 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R522 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R523 963121006310M 470K-J,1/5W-52RE-AX C00004746P520S 1
R524 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R525 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 1
R526 963125012630S 22-J,1W-5REEL C060022065050S 1
R527 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R528 nsp 1.2K-J,1W-5REEL C060012265050S 1
R529 nsp JUMPER (0.6/52MM) L045084006040S 1
R530 nsp 47-J,1W-R.REEL C060047065060S 1
R531 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R532 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R534 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R536 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R537 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R538 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R539 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R540 nsp JUMPER (0.6/52MM) L045084006040S 1
R541 nsp 150K-J,1/5W-52RE-AX X400E3,E3 C00001546P520S 1
R541 nsp 120K-J,1/5W-52RE-AX X2000E1C,E2,K C00001246P520S 1
R542 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R543,544 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R545 963125012630S 22-J,1W-5REEL C060022065050S 1
R546 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R547 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R549 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R551 00D9639005639 100-J,1W-R.REEL C060010165060S 1
R553 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R554,555 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R556 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R557 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R558 00MGD05152160 1.5K-J,1/5W-52RE-AX C00001526P520S 1
R559 963121006300M 33K-J,1/5W-52RE-AX C00003336P520S 1
R560 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R561,562 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R564 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R565 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R566 963121006310M 470K-J,1/5W-52RE-AX C00004746P520S 1
R567 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R568 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 1
R569 963125012630S 22-J,1W-5REEL C060022065050S 1
R570 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R571 nsp 1.2K-J,1W-5REEL C060012265050S 1
R572 nsp JUMPER (0.6/52MM) L045084006040S 1
R573 nsp 47-J,1W-R.REEL C060047065060S 1
R574 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R575 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R577 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R580 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R581 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
