Denon AVR-E400 Service Manual

7CH_AMP
12
REF No. Part No. Part Name Remarks Q'ty New Ver
C401 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C403 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C404 00D9630312402 220UF-M/50V,10*12.5 SMS SY (Pb Free) D040221087140S 1
C405 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C406 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C407 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C408 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C410 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C412 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C413 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C415,416 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C418 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C419 00D9630324005 100UF-M/100V,10*16-S.BULK,MHA-SY D04010108C240S 1
C420 00D9630312402 220UF-M/50V,10*12.5 SMS SY (Pb Free) D040221087140S 1
C421 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C422 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C423 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C424 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C426 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C428 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C429 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C434 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C436 00D9630312402 220UF-M/50V,10*12.5 SMS SY (Pb Free) D040221087140S 1
C437 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C438 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C439 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C440 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C442 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C444 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C445 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C450 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C452 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C453 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C454 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C455 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C456 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C458 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C460 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C461 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C466 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C468 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C469 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C470 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C471 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C472 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C474 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C476 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C477 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C479,480 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C482 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C484 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C485 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C486 963133501540S ST-0.00022UF-J/100V-5RE
D02022106C050S 1
＊
C487 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C488 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C490 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C492 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C493 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C498 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C500 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C501 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C502 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
＊
C503 963134501660S 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C504 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C506 963134001860S 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C508 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
＊
C509 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C511,512 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C513,514 00D9630338402 330UF-M/6.3V,6.3*11-5RE SMS SY D040331081050S 2
C515 00D9630324607 47UF-M/10V,5*11-5RE SMS SY (Pb Free) D040470082060S 1
OTHER PARTS GROUP
BKT400 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CN404 963612504740D 170MM/5P 20010HS-05=CKM2002HV-05 YW1007#26 L002171050080S 1
CP401 nsp 20010WS-13A00 DIP13P STRAIGHT L101200101310S 1
CP402 nsp 5267-05A 5P L102526700500S 1
CP403 nsp 20010WS-10A00 DIP10P STRAIGHT L101200101010S 1
CP405 nsp 5267-03A 3P L102526700300S 1
G400 nsp 60MM/1P B1813T0P-2*2 BK1007#20 L000600010050S 1
G402 nsp 60MM/1P B1813T0P-2*2 BK1007#20 L000600010050S 1
J401 nsp JUMPER (0.6/52MM) L045084006040S 1
J404-413 nsp JUMPER (0.6/52MM) L045084006040S 10
J415 nsp JUMPER (0.6/52MM) L045084006040S 1
J417-441 nsp JUMPER (0.6/52MM) L045084006040S 25
J443-467 nsp JUMPER (0.6/52MM) L045084006040S 25
J469-493 nsp JUMPER (0.6/52MM) L045084006040S 25
J495-517 nsp JUMPER (0.6/52MM) L045084006040S 23
J519 nsp JUMPER (0.6/52MM) L045084006040S 1
J521-534 nsp JUMPER (0.6/52MM) L045084006040S 14
J536 nsp JUMPER (0.6/52MM) L045084006040S 1
J538 nsp JUMPER (0.6/52MM) L045084006040S 1
J540-543 nsp JUMPER (0.6/52MM) L045084006040S 4
J545 nsp JUMPER (0.6/52MM) L045084006040S 1
J547-557 nsp JUMPER (0.6/52MM) L045084006040S 11
J560-571 nsp JUMPER (0.6/52MM) L045084006040S 12
J573 nsp JUMPER (0.6/52MM) L045084006040S 1
J575-585 nsp JUMPER (0.6/52MM) L045084006040S 11
J587,588 nsp JUMPER (0.6/52MM) L045084006040S 2
J590 nsp JUMPER (0.6/52MM) L045084006040S 1
J592 nsp 0-J,1/16W-1608REEL C20000006M160S 1
J598 nsp JUMPER (0.6/52MM) L045084006040S 1
JP518 nsp JUMPER (0.6/52MM) L045084006040S 1
JP535 nsp JUMPER (0.6/52MM) L045084006040S 1
JP537 nsp JUMPER (0.6/52MM) L045084006040S 1
JP539 nsp JUMPER (0.6/52MM) L045084006040S 1
JP544 nsp JUMPER (0.6/52MM) L045084006040S 1
JP558 nsp JUMPER (0.6/52MM) L045084006040S 1
JP574 nsp JUMPER (0.6/52MM) L045084006040S 1
TP401-407 nsp 20010WR-03A00 DIP3P RIGHT ANGLE L101200100320S 7
VR401-407 963161012400S EVN-DCAA03B13/REEL 1KB C541102315000S 7

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
