Denon AVR-E400 Service Manual

HDMI
13
HDMI PCB ASS'Y
NOTE:
X2000E3 : U.S.A. & Canada model X2000E2 : Europe model X2000E1C : China model X2000E1 : Asia model X2000K : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1001 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1313 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D2401 00D2760739907 KDS181S(B)-THICK SOT-23 K005018100040S 1
D3001 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE X2000E3 K125521305230S 1
D3002 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 X2000E3 K005041480230S 1
D3006 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE X2000E3 K125521305230S 1
D3007 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D3008,3009 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 2
D3201 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D3401 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D3602 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
Q1001-1004 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 4
Q1005-1008 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 4
Q1303-1305 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 3
Q1606 963223500020D UPA672T-T1-A SC-88 J543672001010S 1
Q2202 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q3001 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA X2000E3 J522305200050S 1
Q3002 943215500030S RT1P441C 0.2W/SC-59 ISAHAYA X2000E3 J520104411210S 1
Q3201 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3202 963219002180S 2SD2114KT146W SMT3 SOT23-REEL J5232114K0010S 1
Q3203 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3204 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
Q3205,3206 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
Q3207 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
Q3208 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3209 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q3210 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3211 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q3212 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3213-3216 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 4
Q3217 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3218,3219 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 2
Q3220 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3601-3605 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 5
Q3606,3607 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 2
Q3608-3612 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 5
Q3613,3614 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 2
Q3615-3618 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 4
Q3620 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
Q3621-3624 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 4
Q3626 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q3627 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q3629 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
U1001 236810057606S ADV3002BSTZ 4-TO-1 HDMI SWITCH TQFP80 J040300205510S 1
U1201 nsp AD8195 HDMI/DVI BUFFER EQ LFCSP40 J040819505510S 1
U1301 943239100760S TC74VHC4051AFT TOSHIBA J040744051360S 1
U1302 963236101220D ADV7850 HDMI 1.4A RECEIVER BGA425 J040785005510S 1
U1601 963236101320S ADV8003-3 BGA425 ADV8003KBCZ-8B SINGLE HDMI TX J045800303010S 1
U1602 963248101680S MX25L12836EMI-10G 128M SERIAL FLASH SOP16 8952400000220 1 ＊ 2
U1603 963231101500S NJM2846DL3-18 1.8V TO-252-5 LOW-DROP VOL REGULATOR J126284618010S 1 ＊
U1801,1802 nsp K4T51163QJ-BCE7 512M J-DIE DDR2 SDRAM FBGA84 J001451163370S 2
U2001 nsp ADSP21487KSWZ-3B3018 SHARC PROCESSOR LQFP176 E400E3 J080214875510S 1
U2001 nsp ADSP21487KSWZ-3B3017 SHARC PROCESSOR LQFP176 X2000E1C,E2,E3,K J080214875520S 1
U2002 943246012690S W9864G6JH-6 1M*4BANKS*16BIT(64MB) TSOP54 J001986466010S 1
U2003 963248101700S MX29LV160DBTI-70G 16M(2M*8/1M*16)3V TSOP48 8952400000240 1 ＊
U2201 963239101100S BCR-802-M25 25MBPS OPTICAL RECEIVER INTERFACE E100802000250S 1 ＊
U2202 963239101100S BCR-802-M25 25MBPS OPTICAL RECEIVER INTERFACE X2000E1C,E2,K E100802000250S 1 ＊
U2203 23681014050AS PCM9211 TRANSCEIVER LQFP48 J046921100010S 1
U2204 00D2623077900 TC74VHCU04FT HEX INVERTER TSSOP14 E400E3,X2000E3 J040740405580S 1
U2205 963243101540S 5M80ZT100C5N TQFP100 8952400000230 1 ＊
U2207 963239002150S SN74LVC244APWR TSSOP 20P/OCTAL BUFFER/DRIVER J040742440230S 1
U2401 943239100690S PCM5100 TSSOP20 AUDIO STEREO DAC J042510005510S 1
U2402,2403 943239010400S I.C, REGULATOR(3.3V/TO-252) J126284533010S 2
U2404 nsp PCM1690 HTSSOP48 J042169000010S 1
U2406-2409 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 4 ＊
U2602 23681011260AS DM860A NETWORKED MEDIA PROCESSOR LFBGA320 J080860A05510S 1
U2603 963248101710S H27U1G8F2BTR 1Gbit NAND FLASH TSOP48 TSI 8952400000250 1 ＊ 2
U2604,2605 963246100740D A3V56S30FTP-G6 256Mb SDRAM TSOP54 J001030563060S 2
U2802 nsp LAN8720A ETHERNET TRANSCEIVER QFN24 SMSC J127872005510S 1
U2805 nsp MFI337S3959 COPROCESSOR(IPOD) DENON SAGUB J044337395910S 1
U2806 nsp NCP380HMU15AATBG UDFN6 J127380150010S 1
U3002 963243101520S R5F56108VNFP 32BIT MICROCOMPUTER P-LQFP144 RENESAS 8952400000210 1 ＊ 2
U3003 943239100720S R1EX24256BSAS0A 256Kbit SERIAL SOP8 RENESAS J000242565570S 1
U3202 00D2623676903 TC74VHCT08AFTS1-TBB TSSOP14P QUAD 2-INPUT AND GATE J040740800350S 1
U3203 00D2623444902 TC74VHC08FT CMOS 2-INPUT AND GATE TSSOP14 P-0.65 E400E3,X2000E1C,E2,K J040740800280S 1
U3601-3605 nsp EX3AV 3A VOL DC-DC CONVERTER QFN38 J048030030010S 5
U3608 943239100730S PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1
RESISTOR GROUP
R1001-1004 nsp 1K-J,1/16W-1005REEL C20001026M101S 4
R1005-1008 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R1009-1012 nsp 47K-J,1/16W-1005REEL C20004736M101S 4
R1017,1018 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R1019-1021 nsp 10K-J,1/16W-1005REEL C20001036M111S 3
R1024-1032 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 9
R1033,1034 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1036 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1037 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1039 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1041 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1043 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1045 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1202 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1204 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1205 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1207,1208 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1210,1211 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R1212,1213 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1217 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1303 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1306-1309 nsp 24-J,1/16W-1608REEL C20002406M160S 4
R1311,1312 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1313 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1314,1315 nsp 51-J,1/16W-1608REEL C20005106M160S 2
The symbols in the column "Remarks" indicate the following destinations.
E400E3 : U.S.A. & Canada model
NOTE :
When you replaced,
please update to the
latest version of each
region.

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
