Denon AVR-E400 Service Manual

HDMI
15
REF No. Part No. Part Name Remarks Q'ty New Ver
R2107-2112 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 6
R2113-2118 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 6
R2119,2120 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 2
R2202 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2203 nsp 33-J,1/16W-1005REEL X2000E1C,E2,K C20003306M101S 1
R2205 nsp 150-J,1/16W-1005REEL E400E3,X2000E3 C20001516M101S 1
R2207 nsp 150-J,1/16W-1005REEL E400E3,X2000E3 C20001516M101S 1
R2208 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2209 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2211 nsp 470-J,1/16W-1005REEL E400E3,X2000E3 C20004716M101S 1
R2213 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2216 nsp 47K-J,1/16W-1005REEL E400E3,X2000E3 C20004736M101S 1
R2217 nsp 330K-J,1/16W-1005REEL E400E3,X2000E3 C20003346M101S 1
R2221 nsp 0-J,1/16W-1005REEL E400E3,X2000E3 C20000006M101S 1
R2222 nsp 0-J,1/16W-1005REEL X2000E1C,E2,K C20000006M101S 1
R2224 nsp 820-J,1/16W-1005REEL C20008216M101S 1
R2225 nsp 680-J,1/16W-1005REEL C20006816M101S 1
R2226 nsp 0-J,1/16W-1005REEL X2000E1C,E2,K C20000006M101S 1
R2229,2230 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R2232 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R2235 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2237 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2240-2242 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R2244-2249 nsp 33-J,1/16W-1005REEL C20003306M101S 6
R2251 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2252,2253 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R2254 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2264 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2266-2268 nsp 10K-J,1/16W-1005REEL C20001036M111S 3
R2269,2270 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R2271-2274 nsp 100-J,1/16W-1005REEL C20001016M101S 4
R2275 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2276 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2277,2278 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R2286 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2301 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2402 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2405 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2406,2407 nsp 470-J,1/16W-1005REEL C20004716M101S 2
R2408,2409 nsp 0-J,1/16W-1608REEL C20000006M160S 2
R2410,2411 nsp 100K-J,1/16W-1005REEL C20001046M101S 2
R2412 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2413,2414 nsp 0-J,1/16W-1608REEL C20000006M160S 2
R2415-2430 nsp 15K-J,1/16W-1608REEL C20001536M160S 6
R2438 nsp 300K-J,1/16W-1608REEL C20003046M160S 1
R2443,2444 nsp 0-J,1/16W-1608REEL C20000006M160S 2
R2445-2447 nsp 11K-J,1/16W-1608REEL C20001136M160S 3
R2448 nsp 24K-J,1/16W-1608REEL C20002436M160S 1
R2449,2450 nsp 16K-J,1/16W-1608REEL C20001636M160S 2
R2451,2452 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2453-2468 nsp 820-J,1/16W-1608REEL C20008216M160S 16
R2470,2471 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2474 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2475 nsp 24K-J,1/16W-1608REEL C20002436M160S 1
R2476 nsp 300K-J,1/16W-1608REEL C20003046M160S 1
R2478,2479 nsp 16K-J,1/16W-1608REEL C20001636M160S 2
R2482,2483 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2489-2496 nsp 100-J,1/16W-1608REEL C20001016M160S 8
R2497,2498 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R2501 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2502 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2504,2505 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R2508-2510 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R2604 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2605-2608 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R2609-2611 nsp 10K-J,1/16W-1005REEL C20001036M111S 3
R2612 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2613 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2614 nsp 3K-F,1/16W-1608REEL C20003024M161S 1
R2615-2617 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R2618 nsp 13K-D,1/16W-1608REEL C20001331M160S 1
R2619 nsp 6.2K-D,1/16W-1608REEL C20006221M160S 1
R2620 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2621 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R2622 nsp 1.5K-J,1/16W-1005REEL C20001526M101S 1
R2623-2626 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R2629,2630 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R2631,2632 nsp 10-J,1/16W-1005REEL C20001006M101S 2
R2633 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2634 nsp 2.7K-J,1/16W-1005REEL C20002726M101S 1
R2635 nsp 1.5K-J,1/16W-1005REEL C20001526M101S 1
R2636 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2640 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2641-2644 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R2646 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2647 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2650 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2651,2652 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R2653 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2701-2703 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 3
R2704-2706 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 3
R2707 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2708 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R2709-2716 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 8
R2717 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2718 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2719 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2720 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2721 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2801 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2803 nsp 10-F,1/16W-1005REEL C20001004M100S 1
R2805,2806 nsp 3.3-J,1/16W-1005REEL C2003R306M101S 2
R2812-2816 nsp 33-J,1/16W-1005REEL C20003306M101S 5
R2817 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R2819 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2820 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2822-2825 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R2826 nsp 1.5K-F,1/16W-1005REEL C20001524M100S 1
R2827 nsp 1.5K-J,1/16W-1005REEL C20001526M101S 1
R2828 nsp 10K-J,1/16W-1005REEL C20001036M111S 1

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
