Denon AVR-E400 Service Manual

HDMI
16
REF No. Part No. Part Name Remarks Q'ty New Ver
R2829,2830 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2831 nsp 8.2K-F,1/16W-1005REEL C20008224M101S 1
R2832,2833 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2834 nsp 3.9K-F,1/16W-1005REEL C20003924M100S 1
R2850 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2856 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2859 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2863 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R2864,2865 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3003 nsp 1K-J,1/16W-1005REEL X2000E3 C20001026M101S 1
R3004 nsp 3.3K-J,1/16W-1005REEL X2000E3 C20003326M101S 1
R3005 nsp 2.2K-J,1/16W-1005REEL X2000E3 C20002226M101S 1
R3009 nsp 100K-J,1/16W-1005REEL X2000E3 C20001046M101S 1
R3017 nsp 18K-J,1/16W-1608REEL E400E3 C20001836M160S 1
R3017 nsp 10K-J,1/16W-1608REEL X2000E1C,K C20001036M160S 1
R3017 nsp 0-J,1/16W-1608REEL X2000E2 C20000006M160S 1
R3018 nsp 3.3K-J,1/16W-1608REEL E400E3 C20003326M160S 1
R3018 nsp 10K-J,1/16W-1608REEL X2000E1C C20001036M160S 1
R3018 nsp 0-J,1/16W-1608REEL X2000E3 C20000006M160S 1
R3018 nsp 22K-J,1/16W-1608REEL X2000K C20002236M160S 1
R3019-3022 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R3023 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3024-3029 nsp 33-J,1/16W-1005REEL C20003306M101S 6
R3030,3031 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R3032-3034 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R3035 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3037 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3038 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3042,3043 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R3044 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3045 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3048 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3050 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3051 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3058-3061 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R3062 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R3063,3064 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R3065-3067 nsp 1K-J,1/16W-1005REEL C20001026M101S 3
R3068 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3069-3076 nsp 33-J,1/16W-1005REEL C20003306M101S 8
R3077,3078 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3079 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3081 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3084 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3086 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3088 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3090 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3092 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3094 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3098 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3100 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3103 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R3104-3106 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R3107 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3201 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3202 nsp 2.2M-J,1/16W-1005REEL C20002256M101S 1
R3203 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3204 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3205 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R3206 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3207 nsp 220K-J,1/16W-1005REEL C20002246M101S 1
R3208 nsp 27K-J,1/16W-1005REEL C20002736M101S 1
R3209 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R3211 nsp 1.2K-J,1/16W-1005REEL C20001226M101S 1
R3212-3213 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R3214 nsp 0-J,1/16W-1005REEL X2000E3 C20000006M101S 1
R3215 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3216,3217 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R3218 nsp 0-J,1/16W-1005REEL X2000E3 C20000006M101S 1
R3219 nsp 390-J,1/16W-1005REEL C20003916M101S 1
R3220 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3221 nsp 2.7K-J,1/16W-1005REEL C20002726M101S 1
R3222 nsp 270-J,1/16W-1005REEL C20002716M101S 1
R3223 nsp 470K-J,1/16W-1005REEL C20004746M101S 1
R3224 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3225 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3226 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3227 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3228 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3230 nsp 18K-J,1/16W-1005REEL C20001836M101S 1
R3231 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3232 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3234 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3235 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R3237 nsp 470-J,1/16W-1005REEL C20004716M101S 1
R3238 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3239,3240 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3241 nsp 390-J,1/16W-1005REEL C20003916M101S 1
R3242 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3243 nsp 2.7K-J,1/16W-1005REEL C20002726M101S 1
R3244 nsp 270-J,1/16W-1005REEL C20002716M101S 1
R3245 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R3247 nsp 470-J,1/16W-1005REEL C20004716M101S 1
R3248 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3249 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3250 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3251 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3252 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3401 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3601 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3602 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3603-3605 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R3607 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3609-3611 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 3
R3625 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R3626 nsp 47K-D,1/16W-1608REEL C20004731M160S 1
R3627 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R3628 nsp 120K-D,1/16W-1608REEL C20001241M160S 1
R3629 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R3630 nsp 470K-D,1/16W-1608REEL C20004741M160S 1
