Denon AVR-E400 Service Manual

3.4.DIAGNOSTICMODE(Video/Audio(signal)pathconrmationmode
3.4.1.Specication
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
3.4.2. Starting diagnostic mode
Press the "Power operation (
X
)" button to turn on power while pressing the "ZONE2 SOURCE" and "DIMMER" and "
STATUS
" buttons.
Select "1. SERVICE CHECK" and press "
STATUS
" to start the set in the Diagnostic mode.
In this mode, TUNED, STEREO and RDS are lit in FL display.
3.4.3. Canceling diagnostic mode
Turn off the power by pressing the "Power operation (
X
)" button.
3.4.4 Selecting items
Press
q
button to switch between video items and audio items.
Press
w
or
e
button to select previous or next items.
This unit remote controller
q w e q w e
audio
⇔
video previous next audio
⇔
video previous next
DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR LEFT CURSOR RIGHT
3.4.5Videosystemconrmationitems
g. XX: Refer to the block diagram of the g.XXth.
Conrmation item FL display settings Contents of conrmationRemarks
1
video convert
(analog or HDMI
⇒
HDMI)
V 0 2 : V . C O N V E R T
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE ON
ZONE2 OFF
·CVBS input
⇒
IP Scaler
⇒
HDMI output
·Component input
⇒
IP Scaler
⇒
HDMI output
·HDMI input
⇒
IP Scaler
⇒
HDMI output
·ETHERNET input
⇒
IP Scaler
⇒
HDMI output
(* Input source can be switched.)
2
HDMI pass
(Main)
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
·HDMI input
⇒
HDMI output
·Front HDMI input
⇒
HDMI output
(* Input source can be switched.)
3
HDMI CEC
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE ON
ZONE2 OFF
·When the power supply of a TV is put in the standby mode, make sure that the
power supply of this unit is also put in the standby mode.
·To check ARC path, switch the input source to "TV AUDIO".
(* Input source can be switched.)
4
HDMI audio
(audio: AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR
·HDMI input(PCM , DolbyDigital , DTS)
⇒
Speaker output
·HDMI input(HD audio)
⇒
Speaker output
(* Input source can be switched.)
5
HDMI audio
(audio: TV)
V 0 6 : H . A U D I O - T V
HDMI Audio : TV ·HDMI input(PCM , DolbyDigital , DTS)
⇒
HDMI output (audio output from
connected TV)
(* Input source can be switched.)
6
GUI menu
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE ON
ZONE2 OFF
·GUI display
⇒
HDMI output
(* Input source can be switched.)
g.1
g.2
g.3
g.4
g.5
g.6
30

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
