Denon AVR-E400 Service Manual

3.4.6Audiosystemconrmationitems
g. XX: Refer to the block diagram of the g.XXth.
Conrmation item FL display settings Contents of conrmationRemarks
1
analog pass
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG(xed)
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
2
digital
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong:
all Speakers =Small
SW=Yes
·Digital input
⇒
Speaker output
(* Input source can be switched.)
3
digital
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK(xed)
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
·Digital(PCM) input
⇒
Speaker output
(ZONE2 L, R )
·Digital(PCM) input
⇒
Preout output
(ZONE2 L, R)
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI(xed)
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
·HDMI input
⇒
Speaker output
(* Input source can be switched.)
5
analog A/D
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong:
all Speaker=Small/ SW=Yes
MAIN ZONE: ON
·Analog input
⇒
Speaker output
·Analog input
⇒
Pre OUT (SW)
(* Input source can be switched.)
6
analog amp assign
(Amp assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
·Analog input
⇒
Speaker output
·Analog input
⇒
Pre OUT (ZONE2) AVR-X2000 only
(* Input source can be switched.)
7
analog amp assign
(amp assign: bi-amp)
(AVR-X2000 only)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
8
front height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
g.7
g.8
g.9
g.10
g.11
g.12
g.13
g.14
31

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
