Deutz 1012 - Tensioning Fan; Alternator Belts; Changing Fan; Alternator Belts 1012; Tensioning Coolant; Fuel Pump Belts 1012 E 8. 6.5.7 Changing Coolant; Fuel Pump Belts; Changing Coolant; Fuel Pump Belts

ENGLISCH • Kapitel 6 • Seite 76
6
© 2002
Service and Maintenance 6.5 Belt Drives
Check, tension and change
belts only with the engine off.
Refit belt guard, if provided.
6.5.2 Tensioning Fan /
Alternator Belts
1012
6.5.3 Changing Fan /
Alternator Belts
1012
z Slacken off bolts 1, 2 and 3.
z Press alternator 5 in direction of arrow A until
correct belt tension is achieved.
z Re-tighten bolts 1, 2 and 3.
z Slacken off bolts 1, 2 and 3.
z Press alternator in direction of arrow B.
z Remove and replace belt.
z Tension belt in accordance with 6.5.3.
z Re-tighten bolts 1, 2 and 3.
6.5.4 Tensioning Coolant /
Fuel Pump Belts
1012
z Slacken off bolts 1 and 2.
z Push fuel pump 3 in direction of arrow (A)
until correct belt tension is achieved.
z Re-tighten bolts 1 and 2.
