Engine Description 2.4 Fuel System
2.4.1 Fuel System Schematic
1 Fuel tank
2 Line to fuel pump
3 Fuel pump
4 Line to fuel filter
5 Fuel filter
6 Line to injection pumps
7 Injection pump
8 Line to injector
9 Injector
10 Back leak fuel pipe
11 Banjo bolt with pressure-regulating
valve
12 Fuel check valve
13 Return line to fuel tank
14 Keep this spacing as wide as possible
26239 2
