z Crankshaft Position 1:
Turn crankshaft until both valves in
cylinder 1 overlap (exhaust valve about
to close, inlet valve about to open). Adjust
clearance of valves marked in black on
schematic. Mark respective rocker arm
with chalk to show that adjustment has
been done.
z Crankshaft Position 2:
Turn crankshaft one full revolution (360°).
Adjust clearance of valves marked in
black on schematic.
© 26 263 2
6.6 Adjustments Service and Maintenance
6.6.1.1 Valve Clearance Adjustment Schematic
