SIRIUS® Measurement Modules
5.17.3 HS-ACC+ (Counter) L1B7f
The HS-ACC+ modules are perfect for high speed sound and vibration IEPE channels plus counter applications. In
addition to the HS-ACC module, it also has a 7-pin Lemo connector for digital counters.
Illustration 151: HS-ACC+: counter pin-
out (LEMO 7pin)
Illustration 152: SIRIUS-HS-ACC8+
Connector type L1B7f
Connector on the module: EGG.1B.307.CLL
Mating cable connector: FGG.1B.307.CLAD52
Table 27: HS-ACC+ Counter Specifications (per module)
Digital Output Configuration
The “switch” of the open collector output is closed when active.
5.17.4 HS-ACC: Voltage
Illustration 153: HS-ACC Voltage
Doc-Version: 1.4.2 www.dewesoft.com Page 109/166
