5.4 SIRIUS® Dual Core specifications
High Dynamic: Dual Core with 2x24Bit
Analogue modules ACC CHG HV LV MULTI STG STGM
With counter and DIO ACC+ CHG+ - LV+ - STG+
STGM+
STGM-DB
Isolated version i
■ ■ ■ ■ ■ ■ ■
EtherCAT® version ■ ■ ■ ■ ■ ■ ■
Differential version ■ ■ - ■ ■ ■ ■
Rack version r
12
■ ■ ■ ■ ■ ■ ■
Fanless version f
■ - ■ ■
13
- - ■
Analogue Inputs
14
Inputs per module 1 1 1 1 1 1 1
Data Rate per
Channel [Hz]
USB 200k 200k 200k 200k 200k 200k 200k
EtherCAT® 20k 20k 20k 20k 20k 20k 20k
Vertical Resolution 2 * 24bit 2 * 24bit 2 * 24bit 2 * 24bit 2 * 24bit 2 * 24bit 2 * 24bit
Bandwidth 75 kHz 75 kHz 75 kHz 75 kHz 75 kHz 75 kHz 75 kHz
Voltage
±10 V,
±500 mV
±10 V,
±500 mV
±1200 V,
±50 V
±200 V to
±100 mV
±10 V to
±50 mV
±50 V to
±100 mV
±10 V to ±10 mV
Input coupling
DC, AC 1 Hz
(3,10Hz SW)
DC, AC 0.1, 1,
10, 100Hz
DC DC, AC 1 Hz
(3,10Hz)
DC DC, AC 1 Hz
(3,10Hz SW)
DC
Sensor Excitation - - -
2-30V bipol.
0-24V unipol
max.0.2A/2W
0-12 V (<44mA)
and fixed
12 V, 5 V
0-20 V
max.0.1A/0.8W
0-60 mA
0-12 V,
max. 44mA
Bridge connections
(internal completion)
- - - Full
Full, Half,
¼ .120/350Ω
3-wire
Full, Half,
¼.120/350Ω
3 or 4-wire
Full, Half,
¼ 120/350Ω
3-wire
Programmable Shunt
(default Values)
- - - - 59.88kΩ
59.88kΩ,
175kΩ bipolar
100 kΩ, bipolar
IEPE/ICP Sensors 4 or 8mA 4, 8 or 12 mA - MSI MSI MSI MSI
Resistance - - - MSI MSI ■ MSI
Temp. (Pt100 to Pt2000) - - - MSI MSI ■ MSI
Temp. Thermocouple - - - MSI MSI MSI MSI
Potentiometer - - - - ■ ■ ■
Charge -
100,000 pC,
10,000 pC
- MSI MSI MSI MSI
Current ext. Shunt ext. Shunt - ext. Shunt ext. Shunt ext. Shunt ext. Shunt
TEDS interface ■ ■ - ■ ■ ■ ■
Advanced Functions
Sensor error
detection, high
dynamic range
Sensor error
detection in
IEPE and charge
mode (injection)
High Voltage
High Isolation
High sensor
power and
multi range
Analogue and
digital inputs,
analogue out
Supports all
strain types and
high input range
Low power,
Sensor&Amp.
balance, Bipolar
shunt
Analogue input Connectors
Connector type (Default)
BNC BNC,
TNC
Banana DB9,
BNC,
Banana
DB15,
L2B16f
DB9,
L2B7f,
L2B10f
DB9,
L2B8f
L2B16f
Digital types only on + slices
Counter (connector) 1 ch(L1B7f) 1 ch(L1B7f) - 1 ch(L1B7f)
1 ch(DB15)
1 ch(L2B16f)
1 ch(L1B7f)
1ch(L2B10f)
11
1 ch(L1B7f)
Digital Input (connector) 3 ch(L1B7f) 3 ch(L1B7f) - 3 ch(L1B7f)
3 ch(DB15)
3 ch(L2B16f)
3 ch(L1B7f)
1ch(L2B10f)
11
3 ch(L1B7f)
Digital Output (connector) 1 ch(L1B7f) 1 ch(L1B7f) - 1 ch(L1B7f) -
1 ch(L1B7f)
1ch(L2B10f
)
11
1 ch(L1B7f)
Additional Information
Isolation Voltage
16
1000V 1000V CAT II 1000V 1000V 1000V 1000V 1000V
Power Consumption/Max
17
8W/15W 10W/18W 8W 10W/25W 15W/25W 15W/25W 11W/20W
Table 6: Dual Core Specifications
11 One digital IO per amplifier with Lemo 2B10f connector
Page 54/166 www.dewesoft.com Doc-Version: 1.4.2
DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft®
measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation

DEWESOFT SIRIUS Specifications

General

Resolution	24-bit
Isolation	Channel-to-channel and channel-to-ground
Interface	USB
Software	DewesoftX data acquisition software
Bandwidth	DC to 50 kHz (depending on module type)
Humidity	non-condensing
Analog Inputs	Voltage, IEPE, Charge, Current, Strain Gage, Thermocouple, RTD, Resistance, LVDT, Bridge
