DEWESOFT SIRIUS User Manual

Enclosure Overview
4.4.1 Specifications f-SBOX
Physical Specifications Technical Specifications
Power Supply 9-36V
DC
Processor Intel® Core™ i7-3517UE
Max. Power Consumption 30W CPU clock frequency 2x1.7GHz
Physical Dimensions 265x150x75 [mm] RAM 4 GB
Humidity (@60°C) 95% RH non-condensing Flash S-BOX-FLASH120 option
USB Front: 4x USB 3.0
Rear: 2x USB 2.0
SSD 240GB (960GB as option,
others on request)
Ethernet GLAN, WLAN Chipset Intel QM77
Operating Temperature -20 to 40°C GPS Optional: 10Hz, 20Hz, 100Hz,
RTK
Storage Temperature -40 to 85°C
Humidity 95% RH non condensing @ 60°C
Shock & Vibration VIBRATION SWEEP SINUS (EN 60068-2-6:2008)
VIBRATION RANDOM (EN 60721-3-2: 1997 - Class 2M2)
SHOCK (EN 60068-2-27:2009)
4.4.2 Front Side
Illustration 62: SIRIUS f S-BOX Frontside
4.4.3 Rear Side
Illustration 63: SIRIUS f S-BOX: Connectors at the rear side
Doc-Version: 1.4.2 www.dewesoft.com Page 33/166
DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft®
measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation

DEWESOFT SIRIUS Specifications

General

Resolution	24-bit
Isolation	Channel-to-channel and channel-to-ground
Interface	USB
Software	DewesoftX data acquisition software
Bandwidth	DC to 50 kHz (depending on module type)
Humidity	non-condensing
Analog Inputs	Voltage, IEPE, Charge, Current, Strain Gage, Thermocouple, RTD, Resistance, LVDT, Bridge
