Accessories
7.2.2.1 Pin-out (Power Connector)
Illustration 194: DS-BP2 i
Power Connector
Pin Name L2B3f
Power connector (for Input): ECG.2B.303.CLV
Mating connector (for the cable): FGJ.2B.303.CLAD92
1 V+
2 GND
3 n.c.
Doc-Version: 1.4.2 www.dewesoft.com Page 141/166
