DEWESOFT SIRIUS User Manual

SIRIUS®
Version
Date
[dd.mm.yyyy] Notes
1.4.1 01.10.2015
☑ Updated image of EtherCAT single slice version in chapter 4.2.2: now you see the USB
connector
☑ Updated pin-out images of BNC connectors
☑ SIRIUS® is now a registered trademark
☑ Added chapter 6 Measurement including Anti-Aliasing
☑ Added chapter for Firmware-upgrade
☑ ACC+: corrected Sensor Supply voltage (was 14V – now 12V)
☑ Digital Filter (vs. Sample Rate): removed from Specifications tables and moved to “ADC
oversampling chapter” and corrected the frequency ranges
☑ MSI-BR-TH are now called MSI-TH
☑ Chapter “HS-LV DSUB-9”: corrected connectors and wiring diagrams
☑ CHG and HS-CHG: added missing Input coupling 0.5Hz
☑ Added chapter for “R8D Mounting”
1.4.2 13.11.2015
☑ General Specifications: Updated Humidity, added Acquisition rate – Time base accuracy
☑ HVv2, HS-HV: updated Input Impedance
☑ Corrected description of Illustration in 5.21.2 HS-STG+ (Counter) L1B7f
Page 166/166 www.dewesoft.com Doc-Version: 1.4.2
DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft® DEWESoft®
measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation measurement innovation

DEWESOFT SIRIUS Specifications

General

Resolution	24-bit
Isolation	Channel-to-channel and channel-to-ground
Interface	USB
Software	DewesoftX data acquisition software
Bandwidth	DC to 50 kHz (depending on module type)
Humidity	non-condensing
Analog Inputs	Voltage, IEPE, Charge, Current, Strain Gage, Thermocouple, RTD, Resistance, LVDT, Bridge
