SIRIUS® Measurement Modules
5.10.5.1 LV DSUB-9: Voltage
Voltage - Single Ended
Voltage – Differential
Use only when the sensor is powered by the
excitation voltage of the module.
5.10.5.2 LV DSUB-9: Current
External Direct Shunt External Loop Powered Shunt
Doc-Version: 1.4.2 www.dewesoft.com Page 67/166
