SIRIUS® Measurement Modules
5.11.2.1 MULTI DSUB-15: Voltage
Voltage - Single Ended
Voltage – Differential
Use only when the sensor is powered by the
excitation voltage of the module.
5.11.2.2 MULTI DSUB-15: Current
External Direct Shunt External Loop Powered Shunt
5.11.2.3 MULTI DSUB-15: Potentiometer
Doc-Version: 1.4.2 www.dewesoft.com Page 71/166
