Dexter Laundry WCAD Series User Manual

Labels and Diagrams All WCAD Models
Key Description T-30 0 T-350 T-40 0 T-450 T-60 0 QTY
* Wiring Diagram, Coin, Micro Switch
(120 V)
9506-117-001
Rev A
1
* Wiring Diagram, Coin, Optical (120 V) 9506-117-001
Rev C
1
* Wiring Diagram, Coin, Electronic Ac-
cecptor (120 V)
9506-131-001 1
* Wiring Diagram Easy Card (120 V) 9506-103-001 1
* Wiring Diagram, CN, No Accecptor
(120 V)
9506-390-001 1
* Wiring Diagram, Coin Micro Switch 9506-119-001
Rev A
9506-239-001
Rev A
9506-121-001
Rev A
9506-121-001
Rev A
9506-125- 001
Rev A
1
* Wiring Diagram, Coin, Optical 9506-119-001
Rev C
9506-239-001
Rev C
9506-121-001
Rev C
9506-121-001
Rev C
9506-125- 001
Rev A
1
* Wiring Diagram, Coin, Electronic
Accecptor
9506-133-001 9506-245-001 9506 -135- 001 9506-135- 001 9506-139-001 1
* Wiring Diagram (Easy Card) 9506-105-001 9506-241-001 9506-107-001 9506-107-001 9506-111-001 1
* Wiring Diagram, CN, No Accecptor 9506-392-001 9506-321-001 9506-394-001 9506-394-001 9506-398-001
* Instructions Spin Direction 8507-273-001 8507-273-001 8507-274-001 8507-274-001 8507-274-001 1
* Wiring Schematic, Coin Micro Switch
(120 V)
9506-116-001
Rev A
1
* Wiring Schematic, Coin, Optical (120
V)
9506-116-001
Rev C
1
* Wiring Schematic, Coin, Electronic
Accecptor (120 V)
9506-130-001 1
* Wiring Schematic, Easy Card (120 V) 9506-102-001 1
* Wiring Schematic, CN, (120V) No
Accecptor
9506-389-001 1
* Wiring Schematic, Coin Micro Switch 9506 -118- 001
Rev A
9506-238-001
Rev A
9506-120-001
Rev A
9506-120-001
Rev A
9506-124-001
Rev A
1
* Wiring Schematic, Coin, Optical 9506-118-001
Rev C
9506-238-001
Rev C
9506-120-001
Rev C
9506-120-001
Rev C
9506-124-001
Rev A
1
* Wiring Schematic, Coin, Electronic
Accecptor
9506-132-001 9506-244-001 9506-134 -001 9506-134-001 9506-138-001 1
* Wiring Schematic, Easy Card 9506-104-001 9506-240-001 9506-106-001 9506-106-001 9506-110-001 1
* Wiring Schematic, CN, No Accecptor 9506-391-001 9506-320-001 9506-393-001 9506-393-001 9506-397-001 1
* Transient Voltage Surge Suppressor
Infomational
8507-330-001 8507-330-001 8507-330-001 8507-330-001 8507-330-001 1
* Label High Voltage Warning 8502-614-004 8502-614-004 8502-614-004 8502-614-004 8502-614-004 1
* Label Fusing & Installation 8502-619-004 8502-619-004 8502-619-004 8502-619-004 8502-619-004 1
* Label Quality 8511-001-002 8511-001-002 8511-001-002 8511-001-002 8511-001-002 1
* Booklet Owners 8514-167-001 8514-169- 001 8514 -175-001 8514-177-001 8514-097-001 1
112 113
Part # 8533-072-001 3/22 Part # 8533-072-001 3/22
112 113
Section 9:
Coin Handling
Parts:
Wiring Diagrams
& Schematics &
maintenance Procedures
Machine
Mounting
Installation
& Operation
Programming
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
Coin
Handling
50Hz
Parts
Maintenance
Service Elec.
Compnents
Accessories
Kits &
Assemblies
Wiring
Harnesses
Cabinet &
Front Panel
Rear
View
Cylinder, Seals,
& Bearings
Door
Lock
Loading
Door
Chassis
& Drain
Water Inlet &
Rear Channel
Electrical
Components
Control
Panel
