Dexter Laundry WCAD Series User Manual

A-Series Accessories
WCAD20KCS-10 120 volts 60hz. Single Phase
WCAD20KCS-12 208-240 volts 60hz. Single Phase or Three Phase
WCAD20KCS-12SZ 208-240 volts 60hz. Single Phase or Three Phase
WCAD30KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCAD30KCS-12SZ 208-240 volts 60hz Single Phase or Three Phase
WCAD40KCS-12 208-240 volts 60hz Single Phase or Three Phase
Key Description T-300 T-350 T-40 0 T-450 T-600 QTY
* Kit, Door Gasket Expander
(large)
9732-139-002 9732-139-002 9732-139-002 9732-139-002 9732-139-002
* Kit, Door Gasket Expander
(small)
9732-139-001 9732-139-001 9732-139-001 9732-139-001 9732-139-001
* Hose, Water Supply 3/8” I.D.
x 48”
9990-027-011 9990-027-011 9990-027-011 9990-027-011 9990-027-011 2
* Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 8641-242-000 8641-242-000 8641-242-000 2
* Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 9565-003-001 9565-003-001 9565-003-001 2
* Bevel Washer for 5/8” bolt used
in installations using angle iron
bases
8641-586-002 8641-586-002 8641-586-002 8641-586-002 8641-586-002
* Bevel Washer for 3/4” bolt used
in installations using angle iron
bases
8641-586-003 8641-586-003 8641-586-003 8641-586-003 8641-586-003
* Sealing compound 8538-151-001 8538-151- 001 8538-151-001 8538-151- 001 8538-151-001
* TOR X#20 8545-051-002 8545-051-002 8545-051-002 8545-051-002 8545-051-002
* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 9475-002-002 9475-002-002 9475-002-002 2
* Battery (used on Control PCB) 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001
* VFD Filter options (1 phase)
120v
9732-233-001
* VFD Filter options (3 phase) 9732-234-001 9732-231-001 9732-231-001 9732-231-001 9732-231-001
* VFD Filter options (1 phase)
220VAC
9732-235-001 9732-232-001 9732-232-001 9732-232-001 9732-232-001
* Coin Bearing & Seal Kit 9732-219-001 9732-219-002 9732-219-002 9732-219-004 9732-219-004
* Coin Op CD with OS2 Platform
for A Series Washers Only
9504-015-001 9504-015-001 9504-015-001 9504-015-001 9504-015-001
* Coin Box Assy, Blue Small 9807-099-001 9807-099-001 9807-099-001 9807-099-001 9807-099-001 1
Coin Box Assy, Black Small 9807-099-003 9807-099-003 9807-099-003 9807-099-003 9807-099-003 1
* Mode Light Support 9635-022-001 9635-022-001 9635-022-001 9635-022-001 9635-022-001 1
* MS300 Display 9150-058-001 9150-058-001 9150-058-001 9150-058-001 9150-058-001 *
* A to C Series Kit -12 9732-306-002 9732-306-003 9732-306-004 9732-306-005 9732-306-006 *
* A to C Series Kit -10 9732-306-001 *
Wiring Harness Part # by Model
Key Description T-30 0 T-350 T-40 0 T-450 T-60 0 QTY
* Wiring Harness (Add Bleach Lite
assy included)
9794-001-001 9794-001-001 9794-001-001 9794-001-001 9794-001-001 1
* Wiring Harness, Door Lock 9627-791- 003 9627-791-003 9627-791- 003 9627-791-003 9627-791-004 1
* Wiring Harness,CoinDrop Mech 9627-792-001 9627-792- 001 9627-792-0 01 9627-792- 001 9627-792-001 1
* Wiring Harness,
Drain,Thermo,DoorSol
9627-796-001 9627-796-001 9627-796-001 9627-796-001 9627-796-002 1
* Data Cable 9806-015-001 9806-015-001 9806-015-001 9806-015-001 9806-015-001 1
* Wiring Harness P20/P21 9627-793- 001 9627-793-001 9627-793- 001 9627-793-001 9627-793- 001 1
* Wiring Harness P8/P16 9627-794 -001 9627-794-001 9627-794- 001 9627-794- 001 9627-79 4-0 01 1
* Wiring Harness WaterValve/P19 9627-795-003 9627-795-003 9627-795-003 9627-795-003 9627-795-004 1
* Wiring Harness LED PCB 9627-797-001 9627-797-001 9627-797-001 9627-797-001 9627-797-001 1
* Wiring Harness P5/pressure 9627-800-001 9627-801-001 9627-801-001 9627-801-001 9627-802-001 1
* Wiring Assembly Yel. 32” 8220-064-023 8220-064-023 8220-064-023 8220-064-023 8220-064-023 2
* Wiring Assembly Red 20” 8220-001-282 8220-001-282 8220-001-282 8220-001-282 2
* Wiring Assembly Vio. 24” 8220-118-001 2
* Wiring Assembly Jumper Yel 8220-123-001 8220-123-001 8220-123-001 8220-123-001 8220-123-001 1
* Wiring Assembly Red 28” 8220-062-025 2
* Wiring Assembly Blk. 17” 8220-062-028 8220-062-026 8220-062-026 8220-063-026 8220-062-026 1
* Wiring Assembly Red 17” 8220-062-027 8220-062-025 8220-062-025 8220-063-025 8220-062-025 1
* Wiring Assembly Jumper BLK. 8220-117-002 8220-117-002 8220-117-002 8220-117-002 2
* Wiring Assembly Red 7” 9631-381-018 9631-381-018 9631-381-018 9631-381-018 9631-381-018 1
* Wiring Assembly Blu/Wht 8220-090-009 8220-090-009 8220-090-009 8220-090-009 8220-090-009 1
* Wiring Assembly Blk/Blu 8220-001-231 8220-001-231 8220-001-231 8220-001-231 8220-001-231 1
* Wire Assembly Green 7” 8220-001-478 1
* Harness Power Terminal Block 9627-831-001 9627-831-001 9627-747-003 9627-747-003 9627-747-003 1
Wire Assy-Red 29” 8220-065-030 1
Wire Assy-Blue 29” 8220-065-031 1
Wire Assy-Black 4” 8220-062-023 1
