Dick SM-110 - Filling Cooling Water

Operating instructions, SM-110/-111
Putting the machine into operation
20
6
6.2 Filling cooling water
43
2
1
1
2
Image 4 – Filling cooling water
[4-1] Clamp
[4-2] Handles for lifting out the
machine
[4-3] Water tank
[4-4] Lateral grinding surfaces
3
1. Switch off the machine, pull the mains plug.
2. Open the clamp [4-1].
3. Lift the machine from the handles [4-2] out of the water tank [4-3].
4. Fill the left and right chamber of the water tank with 2 to 2.5 cm of water.
Donotllwaterintothecentralchamber.
5. Place the machine onto the water tank.
6. Close the clamp [4-1].
NOTE
NEVER GRIND DRY
The water is used for cooling in order to prevent the cutting
edge of the knife overheating during the grinding process.
