Operating instructions, SM-110/-111
Servicing and maintenance
37
8
NOTE
Never dry dress the grinding wheel.
6. Dressing process: Switching on the machine. Turn the dressing spindle
[16-6] towards the lateral grinding surface of the grinding wheel until the
diamond touches it.
7. Slowly swivel the pivot lever to the right and left until the diamond no
longer grips. Adjust the dressing spindle slightly clockwise and continue
the dressing process until the grinding surface is clean or runs without
lateral run out. Dismantle the dressing device again after the dressing
process. Fit the screw plug and knife guide again and clean the machine.
8.3 Removing the grinding wheels
Turn around grinding wheels that are worn or damaged on one side. Replace
grinding wheels that are worn or damaged on both sides with new ones.
Grinding wheels are worn when the edge [17-A] on the lateral grinding
surfaces is no longer present.
CAUTION
RISK OF INJURY FROM ROTATING MACHINE PARTS
If the machine is accidentally switched on during maintenance
work, there is a risk of injury due to rotating machine parts.
➾ Always pull the mains plug before carrying out any mainte-
nance work.
1. Pull the mains plug
2. Open both clamps [17-1].
3. Lift the machines out of the water tank by both handles [17-2].
