Operating instructions, SM-110/-111 4
7 Machining workpieces 29
7.1 Knife sharpening 29
7.2 Honing knives 30
7.3 Polishing the knife (only SM-111) 31
8 Servicing and maintenance 34
8.1 Clean the machine 35
8.2 Dressing the grinding wheel 36
8.3 Removing the grinding wheels 37
8.3.1 Additional steps if the grinding wheel is stuck 39
8.4 Installing the grinding wheels 39
8.5 Remove the honing wheels 40
8.6 Installing the honing wheel 42
8.7 Replacing the polishing wheel (only for SM-111) 43
8.8 Check and replace drive belt 44
8.8.1 Dismantling the housing 44
8.8.2 Checking the belt condition 45
8.8.3 Replacingtheatbelt 45
8.8.4 Replacing the round belt 46
8.8.5 Installing the housing 46
8.9 Replacing water stripping brush 47
9 Fault – cause – remedy 50
10 Spare parts 51
11 Accessories 52
12 EC Declaration of Conformity 53
