OPERATOR’S MANUAL
PM200, 200E and 250 Planter Monitors
11001-1444-200702
10 / INSTALLATION
Figure 5
Optional 3D Mounting Bracket
The console must not obstruct the view of the operator or interfere
with the operation of the tractor.
To prevent damage to the console, be sure the snap fully engages
during installation.
Slide console
until snap
engages
Mount on vehicle
with locally acquired
screws (4)
Hole size .250”
Wing adjustment
bolts
