OPERATOR’S MANUAL
PM200, 200E and 250 Planter Monitors
11001-1444-200702
ADDITIONAL MONITOR FEATURES / 27
3. When a digit is highlighted, use the Up or Down Arrow keys to edit
the selected digit. Up Arrow increases the digit; down arrow decreases
the digit.
4. Press Enter to accept the desired entry.
POPULATION ADJUSTMENT (PM250)
A population adjustment provides a means to display populations nearer
the actual versus the sensed seeding rates. This is useful when sensors do
not detect doubles, triples, or when the sensed application rate does not
match the actual application rate.
To Change the Population Adjustment:
1. Highlight the Population Adjust input box and press Enter.
2. Use the Left or Right Arrow key to select a digit for editing.
3. When a digit is highlighted, use the Up or Down Arrow keys to edit
the value displayed.
4. Press Enter key to confirm the selection.
POPULATION FILTER (PM250)
Population filter provides population display stability for planters with fewer
rows. Use the Population Filter to stabilize population and alarm reporting.
To Change the Population Filter Response Rate:
1. Highlight the Population Filter slide.
2. Move the slide to the right (+) when planting high seed rates and to the
left (-) when planting low seed rates.
3. Press the ESC key to return to the Operate screen.
IMPORTANT: Responsiveness increases as the filter slide is moved to
the right (+) while stability decreases. Stability will
increase as the filter slide is moved to the left (-) while
responsiveness decreases.
