Digi XBEE-PRO S3B - P1 (DIO11 PWM1 Configuration); P2 (DIO12 Configuration)

AT commands I/O settings commands
XBee®-PRO 900HP/XSC RF Modules
100
Parameter Description
1 RSSI PWM0 output
2 PWM0 output
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
P1 (DIO11/PWM1 Configuration)
Sets or displays the DIO11/PWM1 configuration (pin 7).
Parameter range
0 - 5
Parameter Description
0 Disabled
1 32.768 kHz clock output
2 PWM1 output
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
P2 (DIO12 Configuration)
Sets or displays the DIO12 configuration (pin 4).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1 SPI_MISO
3 Digital input
