Digi XBEE-PRO S3B - D5 (Dio5 AssociatedIndicator); D6 (Dio6 Rts)

AT commands I/O settings commands
XBee®-PRO 900HP/XSC RF Modules
97
Parameter Description
0 Disabled
1
SPI_MOSI
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D5 (DIO5/ASSOCIATED_INDICATOR)
Sets or displays the DIO5/ASSOCIATED_INDICATOR configuration (pin 15).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
Associate LED indicator - blinks when associated
2 N/A
3 Digital input
4 Digital output, default low
5 Digital output, default high
Default
1
D6 (DIO6/RTS)
Sets or displays the DIO6/RTS configuration (pin 16).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
RTS flow control
