Technical specifications Performance specifications
XBee®-PRO 900HP/XSC RF Modules
16
Performance specifications
This table describes the performance specifications for the devices.
Note Range figure estimates are based on free-air terrain with limited sources of interference. Actual
range will vary based on transmitting power, orientation of transmitter and receiver, height of
transmitting antenna, height of receiving antenna, weather conditions, interference sources in the
area, and terrain between receiver and transmitter, including indoor and outdoor structures such as
walls, trees, buildings, hills, and mountains.
Specification
Value
Ideal RF line-of-sight
range
10 kb/s: up to 9 miles (15.5 km)
200 kb/s: up to 4 miles (6.5 km)
(with 2.1 dB dipole antennas)
Transmit power output 24 dBm (250 mW) (software selectable)
RF data rate (high) 200 kb/s
RF data rate (low) 10 kb/s
Serial UART interface Complementary metal–oxide–semiconductor (CMOS) Serial universal
asynchronous receiver/transmitter (UART), baud rate stability of <1%
Serial interface data
rate (software
selectable)
9600-230400 baud
Receiver sensitivity
(typical)
-101 dBm, high data rate
-110 dBm, low data rate
Power requirements
The following table describes the power requirements for the XBee-PRO 900HP RF Module.
Specification Value
Supply voltage 2.1 to 3.6 VDC
1
Transmit current PL = 4: 215 mA typical, (290 mA max)
PL = 3: 160 mA typical
PL = 2: 120 mA typical
PL = 1: 95 mA typical
PL = 0: 60 mA typical
Idle/receive current 29 mA typical at 3.3 V (35 mA max)
Sleep current 2.5 µA (typical)
1
Supply voltages of less than 3.0 V may reduce performance. Output power and receiver sensitivity may
degrade.
