Frame descriptions Remote Command Response frame - 0x97
XBee®-PRO 900HP/XSC RF Modules
158
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x13
Frame type 3 0x97
Frame ID 4 0x55
64-bit source (remote) address MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x40
10 0x52
11 0x2B
LSB 12 0xAA
Reserved
13
0xFF
14 0xFE
AT commands 15 0x53 (S)
16 0x4C (L)
Command status 17 0x00
Command data 18 0x40
19 0x52
20 0x2B
21 0xAA
Checksum 22 0xF4
