Item
#
Description
Detail
Indication
Icon
Options / Variants /
Description
If Base is ready to
blast and Wi-Fi/USB
connection is severed
/ lost / disconnected,
this display indicates
the Base is in
READY_TO_BLAST
state
The top figure indicates
a local blast, where RF
is not used or for
remote, when RF is not
connected. Bottom
figure indicates RF
signal
When blasted, to
request user to turn
off power, when Wi-
Fi/USB connection
lost
When in ABORTED
state, and also to turn
off power, when Wi-
Fi/USB connection
lost
