• Multi-Commander: When this option is selected, the user may tag more than 4 channels and up to 16000
detonators on a single Tagger. If not selected it will stop and provide a warning when more than 4
channels are allocated, and more than 1600 detonators are being tagged.
• Autotag: If the Autotag option is disabled (White filled rectangle), tagging can only be performed on the
pogo pins, and not by connecting a detonator onto the harness wire. (It is not practical to connect and then
remove the detonator from the harness wires).
• Multi-Primed: When this item is enabled one can load more than one detonator per hole and tagging can
also be restricted to a deck only if necessary.
• Assign Locations: With large blast designs, the plan may not be complete at the time of tagging and to
speed up the process, tagging can be conducted in parallel with drilling. If this item is checked, the “Tag
Detonators” menu will only write the locations in the detonator.
• List Hole Configuration: Allows users to define a hole configuration.
A hole configuration consists of the number of decks in a hole, the number of detonators in each deck and
the time offset of each deck.
The system allows more than one hole configuration to be defined but only one can be employed at the
time of tagging.
• Det Label: The label defines how the hole (det) is referred to throughout the system.
The following choices are available:
1. Row number, hole number, det number
2. Literal row, hole number, det number
3. Hole Number, det number
4. Numeric sequence (used internally in basic mode)
