The user could set the maximum limit where the leakage warning is triggered. This limit could be set from 0.1 mA
to 1mA in increments of 0.1mA. Note that the default leakage limit is 0.5 mA
1. Main Menu
• Press SoftKey to select Configuration Settings.
2. Configuration Settings Menu
• Press to select 4G Setup
3. 4G Setup
• Press to select Leakage Trigger
• Use navigational keys to scroll up/down and display the required selection
• Set warning trigger between 0.1 and 1mA
• Press SoftKey to save.
The user may test a single detonator while the harness wire is connected on the CE4 Tagger terminals. The user
must ensure that the test single on bus function is enabled by following the steps detailed below:
1. Main Menu
• Press SoftKey to select Configuration Settings.
