Electrical Speci• cations
Power Supply (Vcc):
Operating Range: 8 to 32 V
Range of device constant: k = 500 km"¹ to 65535 km"¹
Resolution of device constant: 1 km"¹
Range of time tariff: 0.10¹ CU/h to 6553.50 CU/h
Resolution of time tariff: 0.10 CU/h
Range of distance tariff: 0.10 CU/km to 6553.50 CU/km
Resolution of distance tariff: 0.10 CU/km
Odometer Transducer Input:
input range: 0 to 32 V
level for LOW voltage: 0 - 0.3 V
level for HIGH input: 5 - Vcc to 32 V
maximum frequency: 1 KHz
high voltage trigger: high - low transition
Passenger Sensor:
Input range: 0 to 32 V
maximum level for LOW input: 1.4 V
Engine Input:
Input range: 0 to 32 V
maximum level for LOW input: 1.4 V
Taxi Light Output:
Maximum Current: 3 A
Output Voltage: Vcc
Lights Outputs:
Maximum Current: 1 A
Output Voltage: Vcc
Printer Power Out:
Maximum Current: direct from Vcc input
Output Voltage: Vcc
RS-232 serial ports: Taximeter COM1, COM2
Android COM5, COM6, COM7
(optional COM8, COM10, COM11, COM12)
Panic Button
