24
External Serial Ports mapping
Serial COM
Digital Input/Outputs
Outputs
Inputs
Inputs
NAME DESCRIPTION
OGP1 General purpose output 1 (external, refer to pin out/cable chapter)
OGP2 General purpose output 2 (external, refer to pin out/cable chapter)
OGP3 General purpose output 3 (external, refer to pin out/cable chapter)
NAME DESCRIPTION
IGP1 General purpose input 1 (external, refer to pin out/cable chapter)
IGP2 General purpose input 2 (external, refer to pin out/cable chapter)
IGP3 General purpose input 3 (external, refer to pin out/cable chapter)
PANIC INPUT Digital Input for Panic Bu! on. Drive to ground.
ENGINE INPUT Digital Input for engine/igni" on signal, ac" ve high
PASSENGER SENSOR Digital Input for Passenger Sensor
ANALOG INPUT 1 Generic Analog Input 1, 10 bits ADC
ANALOG INPUT 2 Generic Analog Input 2, 10 bits ADC
PORT SYSTEM REFERENCE DEFAULT BAUD RATE
COM5 TTYUSB2 User confi gurable
COM6 TTYUSB1 User confi gurable
COM7 TTYUSB0 User confi gurable
COM8 TTYUSB3 User confi gurable
COM10 TTYUSB6 User confi gurable
COM11 TTYUSB5 User confi gurable
COM12 TTYUSB4 User confi gurable
