Digitax X-one - Taximeter Sealing and Operation; Electronic Sealing (E-Seal)

The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third
party is strictly prohibited.
27
The “E-Seal” Reading, is included in the “SelfFuntion Menu”. This is the procedure to enter it:
1) Keep pressed F3 at least for two seconds to enter in the menu selection
2) Select E-Seal menu by pressing F3 key
3) Com• rm by F5 the E-Seal reading.
Now the • rst Record is showed on the display (see • gure 1). To increase the record index press F5; to decrease the re-
cord index press F4. The following pictures are only an example of E-Seal records because every single device could have
a different records sequence.
4) By pressing F5 the E-Seal menu has two options depend-
ing on the event type. In that case showing Bios event type by
pressing F5 we will see the Bios Checksum Programmed. By
pressing again F5 we will go to the next event type.
5) In that event type by pressing F5 we will go to the next
event type (DEFAUL).
6) By pressing F4 we will go to the previous event type
(LB.RES)
BIOS 0
ESeal
operator.IDevent typeidx
25/03/10
12:15
0
(fi gure 1)
7) Press F1 to exit and return to main screen
Note:
At any index position by pressing F2 the E-Seal counters report will be printed
At any index position by pressing F1 the taximeter will come back to For Hire position
E-SEAL
SelFun
K2
K4
BIOS 1555
ESeal
event typeidx
X1G03
0
K4
OP
10.50
For Hire
TimeFARE RsTar
1) Modi• ed Record Number
2) Event type
3) Event Modi• cation Date
4) Event Modi• cation Time
5) Event Value
LB.RES 0
ESeal
operator.IDevent typeidx
25/03/10
1
K4
12:16
DEFAUL 0
ESeal
operator.IDevent typeidx
25/03/10
2
K4
12:16
LB.RES 0
ESeal
operator.IDevent typeidx
25/03/10
1
K3
12:16
1 2
3
4
5
“E-Seal”- Electronic Sealing:
1st Section: Last 100 Reading Changes Done
The “E-Seal” is a non-erasable memory splitted in two sections where, in the • rst section, are recorded the last 100
alterations made on the programming functions. These are shown on the displays or printed, with detailed information
of: index nr, event, date, year and hour. The second section is made of permanent, non-resettable, progressive individual
events counter, incremented by each event alterations without details. The • rst section is by default a FIFO buffer, with the
last 100 events recorded, but can be con• gured by tariff to disable the FIFO and block the taximeter when it reaches its
maximum capacity. The second sections (counters) is never FIFO, and when reaches its maximum capacity of 1000 events
on any counter, the taximeter shows “ESEAL FULL” and it is blocked until the mechanical seal is broken and the taximeter
is again initialized.
MAIN DISPLAY PRINTED REPORT DESCRIPTION EVENTS
K-Cons
K-CONS
Constant “K” calibra! on Autotest
A.DEFL
A.DEFL
A" er checksum error with black key inserted Autodefault
TARIFF
TARIFF
Tari# Programming Tari#
CLOCK
CLOCK
Clock se$ ng Clock
SYN.CL
SYN.CL
Clock +/- 2’ syncro Syncro Clock
TICKET
TICKET
! cket heading programming Header Ticket
M.E.S.
M.E.S.
Mul! extra-charge system programming Mes
CL.MEM
CL.MEM
Sta! s! cal Memory block reset (block 2) Clear memo
DEFAUL
DEFAUL
By manual opera! on General Default
LB.RES
LB.RES
Long Bu# er Memory Reset Long Bu# er Reset
BIOS
BIOS
Firmware changed Bios Change
LIGHTS
LIGHTS
Taxi Roof Lights Test Light Test Result
