The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third
party is strictly prohibited.
61
305
Print all kilometres made for each used tari! ? - Should all kilometres made for each used tariff be printed on the ticket?
The allowed answer is either: 0 (No: don’t print all kilometres made) or: 1 (Yes: print all kilometres made).
No / Yes
306
Print the maximum speed of the trip? - Should the maximum speed of the trip be printed on the ticket?
The allowed answer is either: 0 (No: don’t print maximum speed) or: 1 (Yes: print maximum speed).
No / Yes
307
Use the 4 X 5 matrix for prin" ng? - Should the 4 X 5 matrix be used to print the ticket?
The allowed answer is either: 0 (No: don’t use it) or: 1 (Yes: use 4 X 5 matrix).
No / Yes
308
Hide the driver number on the " cket? - Should the driver number be hidden on the ticket? The allowed answer is either: 0 (No: don’t
hide) or: 1 (Yes: hide).
No / Yes
309
Must the MES (Mul" -Extra Charge System) be enabled?
No / Yes
IR SENSOR FO R PASSENGER DETECTION
310
Distance to enable registra" on or ForHire: this is the distance that enables either the registration of the black fare with a passenger
aboard in Stopped or the automatic activation of Hired. See Q.313. The distance is given in metres with an accuracy of 0.1 meter. The
allowed value goes from 0.0 (min) to 6553.5 (max). The digit indicating multiples of 0.1 m (so at the right of the decimal point) will fl ash.
0 - 65535
311
IR-sensor for passenger-det. is present? - Is the Infra-Red-sensor for the detection of passengers present?
The allowed answer is either: 0 (No: not present) or: 1 (Yes: present).
No / Yes
312
IR-sensor contact is normally closed? - Is the Infra-Red-sensor contact a Normally Closed contact ? If not, then it is a Normally Open
contact.
The allowed answer is either: 0 (No: normally open) or: 1 (Yes: normally closed).
0=open
1=closed
313
Black fare registr. or autom. in Hired? - After the distance programmed in Q.310 should be activated either: the registration in
memory of the black fare with a passenger aboard in Stopped or the automatic activation of Hired?
The allowed answer is either: 0 (No: registration) or: 1 (Yes: pass to Hired).
0 = registration
1 = pass to
Hired
314
Block taximeter if fare-memory is full? - Should the taximeter be blocked when the fare-memory is full?
The allowed answer is either: 0 (No: don’t block) or: 1 (Yes: block).
No / Yes
315
The ForHire led # ashes if IR-sensor is ON? - When the IR-sensor is activated should the ForHire led fl ash?
The allowed answer is either: 0 (No: don’t fl ash) or: 1 (Yes: fl ash).
No / Yes
from Q 316 / Available for any possible software extension / to Q 318
STATISTICAL M EMORY BLOCK N.1
319
Inhibit visualiza" on memory-block n. 1? - Should it be impossible to visualize memory-block number 1? See also Q.320.
The allowed answer is either: 0 (No: visualize) or: 1 (Yes: inhibit).
No / Yes
320
Enable visualiza" on MB1 with password? - If the visualization of memory-block number 1 has been inhibited (see Q.319) should it be
possible to undo this with the password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
321
Inhibit prin" ng memory-block n. 1? - Should it be impossible to print memory-block number 1? See also Q.322.
The allowed answer is either: 0 (No: print) or: 1 (Yes: inhibit).
No / Yes
322
Enable prin" ng MB1 with password? - If the printing of memory-block number 1 has been inhibited (see Q.321) should it be possible to
undo this with the password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
323
Inhibit reset of memory-block n. 1? - Should it be impossible to reset memory-block number 1 from panel? See also Q.324.
The allowed answer is either: 0 (No: reset from panel) or: 1 (Yes: inhibit).
No / Yes
324
Enable reset of MB1 with password? - If the reset from panel of memory-block number 1 has been inhibited (see Q.323) should it be
possible to undo this with the password?
The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
325
Inhibit access to stat. Memory n. 1? - Should it be impossible to have access to the reading-procedure of the statistics-memory number
1?
The allowed answer is either: 0 (No: access) or: 1 (Yes: no access).
No / Yes
To Next Page
