61
AUX INPUT
Connector Type: 1/8” Stereo (Tip-Ring-Sleeve)
Input Impedance: 1 MΩ
Maximum Input Level: +4 dBu DFS
Aux In Audio Path: Maintains analog dry path
FOOTSWITCH INPUT
Connector Type: 1/4” Stereo (Tip-Ring-Sleeve), compatible
with optional DigiTech
®
FS3X 3-button
footswitch
LEFT(MONO)/RIGHT OUTPUTS
Connector Type: 1/4” Unbalanced (Tip-Sleeve)/Balanced (Tip-Ring-
Sleeve)
Output Impedance: 100 Ω Unbalanced/ 200 Ω Balanced
Maximum Output Level: +4 dBu DFS
Playback Unity Gain: Loop Level knob set to 12 o’clock position
PERFORMANCE
Frequency Response: +0/-3 dB 20-20 kHz

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DigiTech JamMan SOLO XT and is the answer not in the manual?

DigiTech JamMan SOLO XT Specifications

General IconGeneral
Sampling Rate44.1 kHz
A/D/A Conversion24-bit
TypeLooper Pedal
StorageInternal, SD Card (optional)
Inputs1 x 1/4" (instrument), 1 x 1/8" (aux in)
Outputs1 x 1/4" (mono)
USB1 x Mini-B
Power Supply9V DC power supply
