Dinli DL702 - Chassis Specifications

【1-7】
GENERAL I
N
F
ORMATIO
N
CHASSIS
Frame Steel
Overall length 2208 mm
Overall width 1129 mm
Overall height 1120 mm
Seat height 916 mm
Wheel base 1305 mm
Front tire 25 x 8 – 12
Rear tire 25 x 10 – 12
Recommended cold tire pressure (front/rear) 35kpa/ 30kpa (5.0psi/ 4.4psi)
Turning radius 6.5m
Fuse 5A, 10A, 15A, 30A
Loading limit (Incl. rider, cargo, etc….) 250kg
Voltage 12V
Battery GS, GTX20L-BS
Ground clearance, unloaded 295 mm
Water crossing maximum depth 520 mm
Front suspension travel 170mm
Rear suspension travel 170mm
Dry weight (approx KGs) 298
Fuel tank capacity 20L
Throttle lever free play 3~8 mm
Air filter Foam
Brake fluid DOT 4
Brake pad thickness (MIN) 3.5 mm
Brake disc thickness (MIN) 4 mm
Drive system Shaft
