Dinli DL702 - Electrical Specifications

【7-2】
E
LECTRICAL SYSTE
M
Specifications
Item Standard
Battery Capacity
12 V ; 18A/h
Alternator type Three-phase AC
Charging voltage (Regulator/rectifier output) 14~15 V
Alternator output voltage
DC14V-23A @ 3000 rpm
Stator
Charge Coil
Y1-Y2 0.52 Ω
Y2-Y/R 0.49 Ω
Y/R-Y1 0.49 Ω
Y-Ground ∞
Pulser Coil
W/R-W 110 Ω
W-Grnd
Ignition Coil
Primary 0.3 Ω
Secondary
6.3 kΩ
Spark plug
Gap
0.8~0.9 mm
Cap resistance
5 kΩ
Starter motor
Nominal Output
0.7 kW
Reduction Ratio
28.235
