DAG2000 Series FXS Voice Gateway User Manual
19
Dinstar Technologies Co., Ltd.
Table 4.5-1 VLAN parameter configuration
Data VLAN
Data 802.1Q VLAN ID(0-4095)
Fill out an ID to describe a data VLAN group,ID 0 used
to management VLAN, can’t used to service
configure.
Data 802.1p Priority（0-7）
802.1p protocol to control network traffic priority,
Priority from 0-7.
Voice VALN
Voice 802.1Q VLAN ID(0-4095)
Fill out an ID to describe a voice VLAN group, ID 0
used to management VLAN, can’t used to service
configure.
Voice 802.1p Priority（0-7）
802.1 protocol to control network traffic priority,
Priority from 0-7.
IP address
Can use dynamic or static IP address
Voice VLAN DNS Server
Can use dynamic or static DNS server address
Management
VLAN
Management 802.1Q VLAN
ID(0-4095)
Fill out an ID to describe a data VLAN group, ID 0
used to management VLAN, can’t used to service
configure.
Management 802.1p Priority
（0-7）
802.1 protocol to control network traffic priority,
Priority from 0-7.
IP address
Can use dynamic or static IP address
Management VLAN DNS server
Can use dynamic or static DNS server address
【Note】： Restart the device to take configuration effect.
4.5.3 ARP
ARP brief introduction:
ARP is address resolution protocol. After configuring ARP, users can get physical address
through device IP address. Under TCP/IP network environment, each host is assigned a
32-bit IP address. But the message transmission needs to know the purpose the physical
address of the party. ARP is a tool that converts IP address into MAC address.
ARP configuration interface as follows:
