DAG2000 Series FXS Voice Gateway User Manual
41
Dinstar Technologies Co., Ltd.
4.9.5 Tel-IP/Tel Routing
Figure 4.9-5 Tel-IP/Tel Parameters Configuration
Routing priority :0-31, 0 is the highest priority.
its purpose is so you can identify the routing with a meaningful name
Tel-IP call select port or port group
Caller number Prefix, its length normally less or equal to caller number, which
helps to matching routing exactly. if caller number is 2001, the caller prefix
can be 200 or 2. “any” means match any caller number like “bob1”,”29801”
Called number Prefix, its length normally less or equal to called number,
which helps to matching routing exactly. if called number is
008675526456659, the called prefix can be 0086755 or 00., “any” means
match any called number
This call routing is routing to port, port group, IP trunk and SIP server.
