JT100/JT100 All Terrain Operator’s Manual Systems and Equipment - 153
Electric Strike System
Troubleshoot Strike System
When strike system detects a problem, an error code will be displayed. Anytime this happens, press self
test button to retest. If error code is still displayed and does not appear in this chart, have control module
checked or replaced.
Other problem situations and their possible causes and solutions are listed in the chart below.
Problem Possible cause Possible solution
ESID detected but
not OK. Red icon
shown on machine
display.
Problems in startup Go to ESID menu and select test
function. If problem goes away, retest
strike system
No power to strike system
control module
Check drilling unit electrical system
Check that harness from drilling unit
to control module is connected
Check that cable from drilling unit
carries more than 10V
Defective control module Have control module checked or
replaced
Defective CAN bus connection Ensure CAN cable from drilling unit to
ESID control module is connected
dc513 Test Wire shows on
machine display
Test wire not connected Check that test wire is connected to
ESID control module
Check that test wire is connected to
machine display
Have ESID control module checked
or replaced
Strobe light on drilling unit
does not work during total
test
Improper connections with
control module
Check connections and wiring
harness
Defective strobe light 1. Disconnect strobe and connect to
external 12V power source.
2. If strobe does not work, replace it.
Defective control module Have control module checked or
replaced
Alarm on drilling unit does
not work during total test
Improper connections with
control module
Check connections and wiring
harness
Defective alarm 1. Disconnect alarm and connect to
external 12V power source.
2. If alarm does not work, replace it.
Defective control module Have control module checked or
replaced
