Controls - 40 JT100/JT100 All Terrain Operator’s Manual
Left Control Console
JT Drilling Controls
1. Spindle brake switch
2. Set/resume switch
3. Rotation speed control
4. Rotation tachometer
Item Description Notes
1. Spindle brake switch To engage, press
To disengage, press
IMPORTANT: Use when making
directional change.
2. Set/resume switch To resume operation or
increase operation levels,
press green part of switch.
To set operating conditions or
reduce operation levels,
press white part of switch.
See “Cruise Control” on page 174.
