39
IP2246EN
EN
With the third level menus enabled ( ), the microSD card inserted and the
automation idle, go to
to export all the control panel parameters to the mi-
croSD. The LCU40H_INFO.txt text file created on the microSD contains all the alarm
counters, the log showing the last twenty alarms, the operating statistics and the
complete configuration of the control panel.
By inserting the microSD in a PC and opening the file LCU40H_INFO.txt with the
Ditec software, you can view all the control panel data.
The
Ditec LCU40H control panel can record every event and/or alarm for every op-
eration performed.
To do this, you must leave a microSD inserted in the relative connector and then, with
the third level menus enabled (
), set .
In this way, at the end of every operation the control panel will save all the events
recorded up to that moment on the microSD (in the LCU40H.log file in the LCU40H_
LOG folder).
You can view all the recorded logs by inserting the microSD in a PC and opening the
LCU40H.log file using the Ditec software.
This is an example of the visualisation of recorded events:
12.1.3 Exporting information on the microSD
12.2 Extended data logging on microSD
NOTE: when the installation is complete, you are advised to delete the internal data
logging.
