DITEC LCU40H User Manual

15
IP2246EN
EN
7.3 Up-and-over doors with two parallel motors
When the Ditec LCU40H control panel is used in applications for automations
with up-and-over doors with two parallel motors, the following connections
can be made:
(Fig. 7.5) Installation with mechanical end stops for opening and closure, and without the use of electric limit
switches.
[Fig. 7.6] Installation with electric limit switches for deceleration during opening and closure.
[Fig. 7.7] Installation with electric limit switches (stop during opening and closure).
[Fig. 7.8] Installation with electric limit switches (stop during opening and proximity during closure).
24V=24V=
A C
1N4007
3635 34 3332 31
MotoreMotore
12
24V=24V=
A C
1N4007
3635 34 3332 31
MotoreMotore
12
24V=24V=
363534 3332 31
MotoreMotore
12
24V=24V=
A C
1N4007
363534 33 32 31
MotoreMotore
12
Fig. 7.5
Fig. 7.6
Fig. 7.7 Fig. 7.8
Motor
Motor MotorMotor Motor
Motor Motor Motor
