11.2.1 Selection of automation type → and specific default
settings
AS
Type of
automa-
tion
Model
CM
Motor
circuit
R1-R2
Thrust
on
obsta-
cles and
current
VA - VC
Speed
during
opening
and
closure
VR
Learn-
ing
speed
PO-PC
Ap-
proach
speed
TA
Accel-
eration
time
during
opening
TQ
Accel-
eration
time
during
closure
VM
Ramp
start-up
speed
OBBI3BH
CL
50 24 18 07 2 3 03
ARCBH
70 14 10 06 2 3 03
FACIL3H
50 12 10 05 2 3 03
LUXO3BH-4BH
40 16 12 06 1 2 10
LUXO5BH- 5VBH
(gate wing < 300
Kg or 3,5 m)
OP
40 15 10 06 1 2 10
LUXO5BH- 5VBH
(gate wing > 300
Kg or 3,5 m)
50 12 08 05 1 2 10
ARC1BH (gate
wing < 250 Kg &
3 m)
CL
50 08 06 05 2 3 03
ARC1BH (gate
wing > 250 Kg or
3 m)
60 06 05 04 2 3 03
DOR1BH-1BHS
(gate wing < 300
Kg or 1+1 m)
50 08 06 05 2 4 03
DOR1BH-1BHS
(gate wing > 300
Kg or 1+1 m)
60 06 05 04 3 6 02
CUBIC6H-6HV-
30H
60 12 08 06 2 3 05
BOX3SH
50 10 06 05 1 5 03
DOKE
OP 50 15 08 05 1 1 03
PWR25H
CL
50 18 10 05 2 3 03
PWR35H
50 20 12 06 2 3 03
PWR50H (gate
wing < 300 Kg or
3,5 m)
OP
40 15 10 06 1 2 10
PWR50H (gate
wing > 300 Kg or
3,5 m)
50 12 8 05 1 2 10
PWR40H
CL 40 22 15 06 1 2 10
