dixell IC200CX Series User Manual

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
CF 54
Power supply frequency
0= disabled
1= Frequency 50 Hz and only signalling alarm
2= Frequency 50 Hz and alarm (all output OFF in case of alarm)
3= Frequency 60 Hz and only signalling alarm
4= Frequency 60 Hz and alarm (all output OFF in case of alarm)
(ATTENTION: if the condenser fan is not controlled by cut of phase
signal (PWM) the parameter CF54 can be configured at 0 value and
the frequency alarm is not enabled)
0 4
Serial Address
CF 55
Serial address 1 247
CF 56
Firmware Release (this parameter is only in reading)
CF 57
Eeprom parameter map (this parameter is only in reading)
Enabling compressors
CF 58
Enabling compressors
0= chiller and heat pump
1= only chiller
2= only heat pump
0 2
Pr1
Password 0 999
Pr2
Password 0 999
Pr3
Password 0 999
Dynamic Setpoint
Param
eters
Description min max M. u. Resolu
tion
Sd 1
Maximum offset for dynamic setpoint function in chiller -30.0
-54
30.0
54
°C
°F
Dec
int
Sd 2
Maximum offset for dynamic setpoint function in heat pump -30.0
-54
30.0
54
°C
°F
Dec
int
Sd 3
Setpoint of outside temperature for dynamic setpoint function in chiller -50.0
-58
70.0
158
°C
°F
Dec
int
Sd 4
Setpoint of outside temperature for dynamic setpoint function in heat
pump
-50.0
-58
70.0
158
°C
°F
Dec
int
Sd 5
Differential of outside temperature for dynamic setpoint function in
chiller
-30.0
-54
30.0
54
°C
°F
Dec
int
Sd 6
Differential of outside temperature for dynamic setpoint function in
heat pump
-30.0
-54
30.0
54
°C
°F
Dec
int
Pr1
Password 0 999
Pr2
Password 0 999
Pr3
Password 0 999
Energy saving
Param
eters
Description min max udm Risolu
zione
ES 1
Start of the Time band 1 (0÷24) 0 24.00
Hr 10 Min
ES 2
End of the Time Band 1 (0÷24) 0 24.00
Hr 10 Min
ES 3
Start of the Time band 2 (0÷24) 0 24.00
Hr 10 Min
ES 4
End of the Time Band 2 (0÷24) 0 24.00
Hr 10 Min
ES 5
Start of the Time band 3 (0÷24) 0 24.00
Hr 10 Min
ES 6
End of the Time Band 3 (0÷24) 0 24.00
Hr 10 Min
ES 7
Monday: energy saving activated
Automatic unit on-off
0 - 0 7 - 7
ES 8
Tuesday energy saving activated
Automatic unit on-off
0 - 0 7 - 7
ES 9
Wednesday energy saving activated
Automatic unit on-off
0 - 0 7 - 7
