1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 14/72
58 DI18 Opto-insulated digital input 18 (potential free contact)
59 DI19 Opto-insulated digital input 19 (potential free contact)
60 DI20 Opto-insulated digital input 20 (potential free contact)
61 DIC Common digital inputs 1 to 20
70 RL1 Relay 1 normally open contact
71 RL2 Relay 2 normally open contact
72 RL3 Relay 3 normally open contact
73 C Common relays 1, 2, 3 and 4 (MAX 6A)
74 RL4 Relay 4 normally open contact
75 RL3 Relay 3 normally closed contact
76 C Common relays 5, 8 and 9 (MAX 6A)
77 RL5 Relay 5 normally open contact
78 RL6 Relay 6 normally open contact
79 RL7 Relay 7 normally open contact
80 RL8 Relay 8 normally open contact
81 RL9 Relay 9 normally open contact
82 RL10 Relay 10 normally open contact
83 C Common relays 6, 7 and 10 (MAX 6A)
84 RL11 Relay 11 normally open contact
85 RL12 Relay 12 normally open contact
86 RL13 Relay 13 normally open contact
87 C Common relays 12, 13 and 15 (MAX 6A)
88 C Common relays 12, 13 and 15 (MAX 6A)
89 RL11 Relay 11 normally closed contact
90 C Common relays 11 and 14 (MAX 6A)
91 RL14 Relay 14 normally open contact
92 RL14 Relay 14 normally closed contact
93 RL15 Relay 15 normally open contact
94 RS485 Master RS485 Master connection (-)
95 RS485 Master RS485 Master connection (+)
96 RS485 Master RS485 Master connection (insulated gnd)
97 RS485 Slave RS485 Slave connection (-)
98 RS485 Slave RS485 Slave connection (+)
99 RS485 Slave RS485 Slave connection (insulated gnd)
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 Remote Display Connection for VISOGRAPH remote terminal (Vnr)
104 Remote Display Connection for VISOGRAPH remote terminal (+)
105 Remote Display Connection for VISOGRAPH remote terminal (-)
106 Modem Reset NC relay input to reset an external modem (24Vac/dc)
107 Modem Reset NC relay output to reset an external modem (24Vac/dc)
Version with SSR relay
84 RL11 Relay 11 normally open contact
85 RL11 Common relays 11
86 RL12 Relay 12 normally open contact
87 RL12 Common relays 12
88 RL13 Common relays 13
