1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 34/72
4.4.3.2 Mechanical specifications
4 DIN module
4.4.3.3 Electrical specifications
Power Supply: 24Vac +10/-15%, 50/60Hz
20 - 36Vdc
Consumption: from 20VA (Vac), from 15W (Vdc)
Connectors: STELVIO 90° screw connectors for digital outputs (250Vac, 6A max)
Microprocessor: AT91SAM9260 32-bit 200Mhz
Permanent FLASH memory: 128MB, in 8
RAM: 32MB, in 16
Internal clock: standard
4.4.3.4 Plastic container
Mount: On a DIN rail (EN 50022, DIN 43880)
Fastened with screws via the removable plastic flaps.
Material: PC-ABS Thermoplastic
Self-extinguishing: V0 (UL94)
Comparative Tracking Index (CTI): 300V
Colour: Black or White, depending on the model
